Six times harder than platinum, iridium withstands temperatures up to 4,000°FBecause the iridium electrodes of these plugs can be shrunk to only 0.4mm, voltage requirements decrease while firing performance improves360° laser welding of electrode provides a seal that resists wear even in the worst conditionsGround electrode features a tapered cut and U-groove that form a large volume area for the flame's center
Center Electrode Type: Fine Wire
Ground Electrode Shape: Grooved
Ground Electrode Shape: Taper Cut
Heat Range: 8
Product Name: Spark Plug
Spark Gap: 0.9 mm
Thread Reach: 19.1 mm
Electrode Tip Material: Iridium
Center Electrode Projection: Projected
Model: IX24B
Riding Style: Street
Spark Gap: 0.035"
Terminal Configuration: Threaded Stud
Type: Resistor
Units: Each
Electrical Resistance: 5k Ohms
Hex Size: 17.5 mm
Style: Iridium
Weight: 0.05
Height: 0.93
Length: 3.5
Width: 0.96
