DESCRIPTION
Fitments
| Years |
Make |
Model |
| 2019 - 2022 |
BMW |
S1000RR |
Features
Öhlins twin-tube shock technologyFeatures needle profiles for compression and rebound adjustersUpdated design results in improved oil flow guidance and volume control for more precise, consistent damping and better fine-tuningAvailable range of preload and compression adjustment is widerRebound and compression are completely separated within the shock with no risk of cavitationCompletely separate compression and rebound settings36 mm shock primary piston redesigned for improved performance for better traction and feelIndustry standard of minimized shock-to-shock varianceImproved chassis feedback for superior rider feel and enhanced controlSpecs
Reservoir Location: Piggyback
Adjustment Type: Adjustable Spring Preload
Model: TTX GP
Mounting Position: Rear
Adjustment Type: Adjustable Rebound Damping
Adjustment Type: Integrated Hydraulic Spring Preload
Color/Finish: Silver
Color/Finish: Yellow
Product Name: Shock Absorber
Adjustment Type: Adjustable Compression Damping
Adjustment Type: Adjustable Length
Bore Size: 1.42"
Damping Method: Compression
Extended Length: Standard
Riding Style: Street
Type: Coilover Twin-Tube
Units: EachApproximate Package Weight & Dimensions
Weight: 9.1
Height: 7.3
Length: 23.4
Width: 10.4
