Programmed to be 'multi class switchable', this #1 feature allows parameters to be instantly reconfigured at the touch of a button to conform to Class 1, 2, or 3 regulations
E-Bike with powerful, dynamic motor system delivering the advantages of electric assist to seamlessly enhance the traditional riding experience
Customizable assist settings to satisfy seasoned riders, enhanced safety features and serviceability built into the fabric or the bike for durability and peace of mind
City tuned 80 Nm/350 W mid motor with Torque/Cadence sensing and throttle delivers a powerful and intuitive natural riding experience
720 Wh battery providing up to 56 mile* rangeready everyday with plug and play charging and all day range
Eco/Tour/Sport/Turbo/Boost user programmable and seamless intelligent riding experience
Frame Hydroformed Alloy, 27.5" frame, internal cable routing head tube ported, removable down tube battery with security lock, accessory ready rear cargo rack
Fork RST BLAZE-27.5TNL-15, 80 mm travel, lockout, Thru Axle
Shifters SHIMANO ALIVIO 9-speed Rapidfire Plus
Chainrings 42T with Narrow Wide teeth
Chain KMC E9-S
Rear Derailleur SHIMANO ALIVIO 9-speed
Cassette SHIMANO ALIVIO 9-speed 11-34T
Handlebar 640 mm, 45 mm rise, 31.8 mm diameter
Grips VELO, Ergonomic, 135 mm
Stem 80 mm with 7 rise
Seat Post 31.6 mm (350 mm)
Saddle SELLE ROYAL Rio
Brake Levers TEKTRO HDE350 with power cut off switch
Brake Calipers TEKTRO HDE350 Hydraulic Disc
Rotors 180 mm
Tires WTB GROOV-E 27.5x2.4, 60tpi
Rims 27.5, Dual Wall Alloy, black
Bluetooth iGO Mobile App (Android and iOS). Customizable profile and performance settings with full diagnostic monitoring and alerts.
Display Unit 2 HD High Brightness IPS Color LCD Display, Ergonomically Designed Buttons, IP65 Waterproof, Password Protected Power On Option, USB Charging Port, Light Auto On/Off Option (Ambient Light Detector), Interface Color Coded Display Reference (for Quick Glance Safety), Main Power/PAS Control/Ride, Stats and Settings Toggle, PAS Level/Battery/Power/Clock, Speedometer/Max Speed/Avg Speed, Trip Distance, Battery Voltage/Capacity Percentage/Range/Accumulated Charging Cycles, Motor Power Output Average/Maximum, Ride Analysis Statistics, Diagnostic and Warning Information, Walk Assist
Motor iGO DRIVE LS 350W mid motor, 48V
Torque up to 100 Nm
Battery 5000mAh SAMSUNG cell, removable with security lock (48 V | 15 Ah | 720 Wh)
Range 56 miles*
Pedal Assist System Eco/Tour/Sport/Turbo/Boost color coded per PAS level
Throttle On-Demand, Removable
Sensor Internal Torque, Cadence, Speed
Class Class 2 Model, configurable to Class 1 or Class 3 capable where permitted**
Front LED light XC-259A (powered by main battery), Rear LED SPANNINGA LED Commuter Glow XE with brake light Integrated into rear rack (powered by main battery), Front & Rear Fenders, Rear Cargo Rack Accessory ready, Integrated Chainring Guard, Water Bottle Bosses on Seat Tube, Kickstand, Wellgo Pedals, Bell, Tool Kit, Battery Charger
Battery Weight 7.7 lb
Weight Capacity 275 lb
Specs
Brake Lever: TEKTRO HDE350 with power cut off switch
Cassette: SHIMANO ALIVIO 9-speed 11-34T
Chain: KMC E9-S
Motor: iGO DRIVE LS 350W mid motor, 48V
Range: 56 miles*
Rims: 27.5, Dual Wall Alloy, black
Style: Step Through
Brake Calipers: TEKTRO HDE350 Hydraulic Disc
Battery Capacity: 48V15Ah
Product Name: Bicycle
Riding Style: Bicycle
Style: Urban/Leisure
Units: Each
Maximum Rider Weight: 275 lb
Model: Discovery LS
Type: Electric
Weight: 63.9 lb
Battery: 5000mAh SAMSUNG cell
Battery Capacity: 720 Wh
Chainrings: 42T with Narrow Wide teeth
Class: Class 2 Model, configurable to Class 1 or Class 3 capable where permitted **
